Physical Length: 18.9" Width: 8.3" Height: 15.3" Net Weight: 30.8 Lbs.
Performance Fluid consumption (100%): 300 ml/min (1%): 70 ml/min Ready time: 8 Min.
Control and Programming Control options: DMX / RDM, Modbus RTU, Cable remote control, radio remote control (optional), integrated timer, stand-alone Fog Variable output control, 0-100% DMX channels: 1
Protocols: DMX512, RDM, Modbus RTU, JT remote
Construction Housing: Metal Color: Red and Black
Display: 1.3" OLED Display, Membrane Keyboard
Fluid pump: Dual oscillating piston, high pressure Fluid reservoir: 5L drop-in reservoir
Installation Mounting: Standing or hanging Orientation: Up to +/-40° from horizontal |
Connections
AC Power: PowerCON TRUE1, L6-20P DMX, link mode in/out: 5-pin locking XLR
Electrical US Model:AC power: 230 V, 50-60 Hz Main fuse: 15A, 250 V Typical power and current: 3100 W
*Measurements made at nominal voltage. Allow for a deviation of +/- 10%.:
Included Items
- Fluid reservoir, 5L Tank
- Power input cable: PowerCON TRUE1
- SG-XLR commander wired remote
Accessories
Fog Scent Additives
XLR Dial Remote
12' XLR cable
Approved fluids*:
Water-Based Training Smoke Fluids
*Various sizes available - contact us or see 'Fluids' product pages for details
|
